a-si thin-film solar module 110W,high efficiency

  • 1 - 9 Pieces
    $75.00
  • >=10 Pieces
    $60.00
Material:
Amorphous Silicon
Max. Power:
110W
Number of Cells:
119
Lead Time:
Quantity(Pieces) 1 - 1000 >1000
Est. Time(days) 14 Negotiable
Customization:
Customized logo (Min. Order: 1 Pieces)
Customized packaging (Min. Order: 1 Pieces)

More

Graphic customization (Min. Order: 1 Pieces) Less
Samples:
$3.00 /Piece | 1 Piece (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
AmpleSun
Model Number:
ASF110
Size:
1.1*1.4
efficiency:
7%
certification:
TUV, CE, IEC, ISO, UL, PV CYCLE, CEC,etc
Front color:
dark brown
Warranty:
25 Years Output Power Guarantee
Solar cell:
amorphous silicon
Cable:
2.5mm2, 750mm length
Junction Box:
MC3 or MC4
Glass:
3.2mm Tempered Low Iron
Frame:
Anodized Aluminium Alloy
TPT back sheet:
White or black Back Sheet
Type:
Standard Solar Panel
Supply Ability
Supply Ability:
25 Milliwatt/Milliwatts per Year
Packaging & Delivery
Packaging Details
Package: Carton
Q'ty/20': 480pcs(48KWp); Q'ty/40': 960pcs(96KWp)
Pcs/ctn: 2pcs/ctn & 28pcs/ctn & 30pcs/ctn
Ctn size: 1.46m*1.13m*0.09m for 2pcs
1.46m*1.16m*1.12m for 28pcs
1.46m*1.11m*1.24m for 30pcs
Loading port: Shanghai
Port
Fob Shanghai
Picture Example:
package-img
Lead Time :
Quantity(Pieces) 1 - 1000 >1000
Est. Time(days) 14 To be negotiated




Company Information

AmpleSun is major in the thin film solar industry, With start-of-art production lines and qualified raw materials, Amplesun provide not only standard thin film photovoltaic modules with high performance and top quality, but also customized products and services.



AmpleSun PV Solar module products types include

  • Framed single glass solar panel
  • Frameless and see through thin film solar module
  • Built-in insulation layer

  • PV-thermal-in-one module

  • Sealed hollow insulating modules

  • Large-area module(much bigger than 1.57m2)

  • Custom size solar panel

Amplesun Solar PV module is widely applied to ground mounted solar power plants, commercial roof systems, residential roofs, BIPV buildings and more. Amplesun clients can order their PV module products with the transparency,size,shape,background color, and even background patterns specified by clients themselves.



Product Features:

1).Use the environmental friendly materials,avoiding any risk to the people and environment in the whole life of our products.

2). Advanced encapsulation process ensures a high resistance against UV, temperature and weather.

3).Coverage with fewer units, and less balancd of system cost.

4).More than 30% lighter than double glass thin film solar modules.

5).Good Weak light performance.

6).Low temperature Coefficients

7).Pretty appearance, well matching the building.



Product Parameters
ModelASF110ASG110
solar panel typea-Sia-Si
Pmax,W110110
Voc.V100100
Isc,A1.791.79
Vpm,V7878
Ipm,A1.411.41
framesingle glass Al-framedouble glass frameless
Encapsulation MaterialEVAPVB











Warranty

Guaranteed free from defects:

Free from defects in materials and workmanship for 5 years.



Guaranteed to maintain power:

Maintain more than 90% of maximum power for 10 years.

Maintain more than 80% of maximum power for 25 years.



Packaging & Shipping

Package: Carton
Q'ty/20': 448pcs(48KWp);
Q'ty/40': 960pcs(96KWp)
Pcs/ctn: 2pcs/ctn & 28pcs/ctn & 30pcs/ctn
Ctn size: 1.46m*1.13m*0.09m for 2pcs
1.46m*1.16m*1.12m for 28pcs
1.46m*1.11m*1.24m for 30pcs
Loading port: Shanghai
